Product range

Order code Description
EV-PEARL-PRO-LK Lynk Pearl Circular IP65 Professional – w/wireless
EV-PEARL-PRO-S-LK Lynk Pearl Circular IP65 Professional – w/sensor – w/wireless
GENERAL FEATURES
  • Wireless meshing system
  • Vandal-proof IK08 rating
  • IP65 weatherproof rating
  • Power monitoring (DT51)
  • Tuneable white (DT8-Tc) controlled by DALI
  • Flicker-free dimming controlled by DALI
  • Emergency and non-emergency models
SENSOR MODELS (-S)
  • Microwave sensor suitable for DALI-2 supporting IEC 62386-303
  • Light level sensor suitable for DALI-2 supporting IEC 62386-304
  • IR remote controllable, custom configurations
  • Corridor mode function in standalone operation
BUILT TO LAST
  • Long life electronics
  • 10 Years Design Life – 100,000 hours at max. ambient
SUITABLE INSTALLATION TYPES (OUT OF THE BOX)
  • IEC62386 over IEC62386-104
  • Wireless monitoring via Ektor Lynk upgrade

This is a non-emergency product This product is also available as emergency Pro model.

Downloads

  • DWG
  • Revit
1 hr

IES

LDT

2 hr

IES

LDT

Normal

IES

LDT

Specifications

General
Supply voltage 240V ~ 50Hz
Ambient temperature 0 to 40°C
Class 2
Wiring Terminal block (1-16 mm □)
IP rating  IP65
IK rating  IK08
Mounting type Surface
Wireless IEC62386-104 over Thread
Lamp power 25 W
Lumens 2500 lm
Colour temp. 3000 to 6000 K
Compliance
Standards
  • AS/NZS 60598.2.1
  • CISPR 15
  • IEC 62386-102
  • IEC 62386-207
  • IEC 62386-209
  • IEC 62386-252
  • IEC 62386-103
  • IEC 62386-303
  • IEC 62386-304
Construction
Body PC
Diffuser PC
Gear tray Powder-coated steel

Pearls
