Product range

Order code Description
EV-RAZOR-16M Slimblade Emergency Exit with 200 × 100 mm decal
GENERAL FEATURES
  • Single and double-sided decals
  • Soft-start charger to reduce building load
  • Available in low illumination area black model, here
  • Fast emergency switch-over (<0.5s) for high-task areas
  • Chain and rod mounting with Surface and Rod Mount Kit
BUILT TO LAST
  • Long life electronics
  • 10 Years Design Life – 100,000 hours at max. ambient
  • High Quality Lithium battery (LiFePO4) and smart charger
SUITABLE INSTALLATION TYPES (OUT OF THE BOX)
  • Standalone (SPU)
  • Self test (AS2293/IEC62034)
  • DALI (IEC62386)
  • Ektor wired monitored system

Downloads

  • DWG
  • Revit
Image module

Accessory range

Order code Description
EV-RAZOR-16M-RM-DECAL Razor Decal Pack 1xright, 1xleft and 1xstraight
EV-RAZOR-LEDFIRE-SM-KIT Surface Mount Kit
EV-RAZOR-LEDFIRE-SM-KIT-B Surface Mount Kit, black
EV-RODMOUNT-WHT Rod mount, incl. bracket for roof /body
EV-RODMOUNT-BLACK Rod mount, incl.bracket for roof /body, black
EV-1500MAH-6.4V-LIFEPO4 1500mAH 6.4V 2 Cell LiFePO4 Battery
EV-WIREDBYCLICK-2.4M-F&P Wire By Click 5-Pin Lead L1025/5, 2.4M
EV-WIELAND-2.4M-F&P Wieland Plug GST18I5S B1 ZR1 S PB02, 2.4M
EV-CMS-2.4M-5PIN CMS 5 Pin Plug Set, 2.4M
EV-WAGO-2.4M-F&P WAGO Plug 5-P Blue 51110475, 2.4M
EV-CMS-2.4M-6PIN CMS 6 Pin Plug Set, 2.4M

Specifications

General
Supply voltage 240V ~ 50Hz
Ambient temperature 0 – 40°C
Class 2
Wiring Terminal block (1-16 mm □)
IP rating IP20
Mounting type
Viewing distance 16M
Decal size 200 × 100 mm
Cut-out 305 x 65 mm
Emergency
Emergency lamp power 0.75W
Rated duration 90 / 120 min (1 / 3 / 4 / 8 hours, selectable)
Classification C0:C40, C90:C32 (2hr)
Emergency testing
  • Standalone
  • DALI Self test
Compliance
Standards
  • AS/NZS 60598.2.22
  • AS/NZS 60598.2.2 (IC-4 rated)
  • AS/NZS 2293.3
  • IEC 60598-2-22
  • IEC 62386-102
  • IEC 62386-202
  • IEC 62034
  • CISPR 15
Battery
Type  LiFePO4
Voltage  6.4V
Code 01302
Charger
Type  Smart charge
Time  16 hours
Operation Multi-state
