In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Standby Power
2.5 W
Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge.
Colour temperature
LED Wattage
1.4 W
Driver
Driver Type
Fixed output
Driver Included
Yes
Dimmable
No
Wiring Type
Re-wireable terminal block (3 pin)
Emergency (EM suffix)
Emergency Mode
Maintained
Emergency Classification
C0:D6.3, C90:E4, C180:E4
Emergency Output Power
1400 mW
Replacement Battery Code
01302
Emergency Duration
90 mins
Viewing Distance
40 m
Decal Size
500 x 250 mm
Emergency Light Source Life
>10Y/00M
AS2293.3-2018 Projection of Light source life for LED Exit signs (appendix E) Defines the projected time until the surface luminance falls below the minimum required surface luminance for an exit sign.
Compliance
Product Design Life
6 years
The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.
