Mechanical
| IP Rating | IP65 |
|---|---|
| IK Rating | IK08 |
| Adjustability | Fixed |
| Fitting Colour | White |
| Product Finish | Powder coated |
| Body Material | Aluminium |
| Diffuser Material | Glass |
| Installation Type | Surface mount |
Electrical
| Working Temp Range | -30 to 50 °C |
|---|---|
| Input Frequency | 50 Hz |
| Maximum Wattage | 120 W |
| Input voltage | 220-240V~ |
| Surge Protection L-N | 6KV |
| Surge Protection L/N-PE | 10KV |
Lamp
| Colour Rendering Index (CRI) | >80 |
|---|---|
| CCT Configuration | Single |
| Macadam Steps (SDCM) | 4-step MacAdam Ellipse |
| Beam Angle | 115 ° |
LED Lifetime
| LED Lifetime | >102000 hrs | ||||||
|---|---|---|---|---|---|---|---|
| This is the Reported LED Lifetime in Hours based on TM-21. Ektor does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below. | |||||||
| LED Lifetime Ratings (Failure rate & lumen depreciation) | |||||||
| |||||||
| This rating defines the performance of the led within its lifetime. L relates to lumen depreciation, where the proceeding number gives the resultant lumen output at the end of it reported lifetime. L70, would mean 30% lumen depreciation which means 70% of its initial output and is tested accordingly to TM-21. The B part refers to failures, which can be define as the percentage of LEDs which fall below the L value in the projected lifetime. A value of B10 refers to 10% failure and a value of B50 refers to 50% failure. After the defined lifetime, the system will reach the defined lumen depreciation and the average led failures is defined by the B rating. The B rating is defined in and tested to IEC62717. | |||||||
| TM-21 Test Hours | 17000 hrs | ||||||
Colour temperature
| 36 Watts | |
|---|---|
| 5000 K | 5700 lm |
| 60 Watts | |
| 5000 K | 10650 lm |
| 80 Watts | |
| 5000 K | 15450 lm |
| 120 Watts | |
| 5000 K | 22400 lm |
Driver
| Driver Type | Fixed output |
|---|---|
| Driver Included | Yes |
| Integrated Driver | Yes |
| Dimmable | No |
| Flex & Plug or Lead Length | 300 mm |
| PSTLM | 0.02 |
| Short Term Light Modulation (PstLM): The requirement is that PstLM should be less than or equal to 1.0. This metric measures the short-term flicker severity and ensures that flicker is not perceptible or is at a level that does not cause discomfort or health issues. | |
| SVM | 0.01 |
| Stroboscopic Visibility Measure (SVM): The requirement for SVM is that it should be less than or equal to 0.4. The SVM metric assesses the visibility of the stroboscopic effect, which can make moving objects appear to be stationary or moving in discrete steps, thus ensuring that this effect is minimized in lighting environments to prevent visual discomfort and safety hazards. | |
Compliance
| Standards |
|
|---|
Warranty
| Commercial Use Warranty | 5 RTB (Total 5 Years) |
|---|---|
| Warranty Operating Hours | 15000 hrs |
| This product is provided with a warranty up until the stated warranty period or until the stated warranty operating hours has been reached (whichever occurs first). | |
