Fitting Colour
IP Rating	IP20
EV-MERCURY-CORE-24M-B EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK	Black
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK EV-MERCURY-CORE EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	White

Body Material	Polycarbonate
Diffuser Material	Polycarbonate
Installation Type	Wall or Ceiling

Maximum Wattage
Working Temp Range	0 to 40 °C
Input Frequency	50 Hz
EV-MERCURY-CORE-24M-B	1.6 W
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	2.5 W
EV-MERCURY-CORE	3.5 W
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	4.5 W

Input voltage	230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Standby Power
EV-MERCURY-CORE-24M-B	1.2 W
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	1.9 W
EV-MERCURY-CORE	2.2 W
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	3 W

Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge.

LED Wattage
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	0.6 W
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	1.5 W

Driver Type
EV-MERCURY-ADV-24M-DA EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-DA	DALI DT1 Emergency
EV-MERCURY-CORE EV-MERCURY-CORE-24M-B	Fixed output
EV-MERCURY-ADV-24M-LK EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	Wireless (IEC62386-104) with DT1

Driver Included	Yes
Integrated Driver	Yes
Dimmable	No
Wiring Type
EV-MERCURY-ADV-24M-LK EV-MERCURY-CORE EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	Re-wireable terminal block (3 pin)
EV-MERCURY-ADV-24M-DA EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-DA	Re-wireable terminal block (5 pin)

Emergency Classification
Emergency Mode	Maintained
EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	C0:C12.5, C90:C32
EV-MERCURY-CORE	C0:D5, C90:D5
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	C0:D6.3 C90:D6.3

Emergency Output Power
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK EV-MERCURY-CORE-24M-B	600 mW
EV-MERCURY-CORE	1000 mW
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	1500 mW

Replacement Battery Code
EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	01300
EV-MERCURY-CORE EV-MERCURY-CORE-24M-B	01307
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-DA	13845
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	13972

Emergency Duration	90 mins
Viewing Distance	24 m
Decal Size	300 x 150 mm
Emergency Control
EV-MERCURY-ADV-24M-DA EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-DA	DALI Monitored (DT1)
EV-MERCURY-ADV-24M-LK EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	IEC62386-104 (Wireless DT1)

DALI Monitored ~ Supports Emergency test and monitoring over DALI (IEC62386) with full compliance to IEC62386-202. IEC62386-104 ~ Supports wireless test and monitoring over IEC62386-104 using IEC62386-202.
Emergency Light Source Life
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	56Y/06M
EV-MERCURY-PRO-24M-DA	>20Y/00M

AS2293.3-2018 Projection of Light source life for LED Exit signs (appendix E) Defines the projected time until the surface luminance falls below the minimum required surface luminance for an exit sign.

Product Design Life
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	12 years
EV-MERCURY-CORE EV-MERCURY-CORE-24M-B	6 years

The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.
Standards	AS/NZS 60598.1 AS 60598.2.22 AS/NZS 61347.1 AS/NZS 61347.2.13 AS CISPR 15 AS/NZS 2293.3

Commercial Use Warranty
EV-MERCURY-CORE EV-MERCURY-CORE-24M-B	5 RTB (Total 5 Years)
EV-MERCURY-ADV-24M-DA EV-MERCURY-ADV-24M-LK	6 RTB (Total 6 Years)
EV-MERCURY-PRO-24M-B-DA EV-MERCURY-PRO-24M-B-LK EV-MERCURY-PRO-24M-DA EV-MERCURY-PRO-24M-LK EV-MERCURY-PRO-LK	8 RTB (Total 8 Years)

Order code	Item code	Description
12281	EV-MERCURY-ADV-24M-DA	Mercury Advanced Emergency Exit 24M - DALI
12562	EV-MERCURY-PRO-24M-B-DA	Mercury Pro Emergency Exit - 24M - Black
12561	EV-MERCURY-PRO-24M-DA	Mercury Pro Emergency Exit - 24M

Order code	Item code	Description
12282	EV-MERCURY-ADV-24M-LK	Ektor Lynk Mercury Emergency Exit 24M - Advanced W/Wireless
12564	EV-MERCURY-PRO-24M-B-LK	Ektor Lynk Mercury Emergency LED Exit 24M - Black - Pro W/wireless
12563	EV-MERCURY-PRO-24M-LK	Ektor Lynk Mercury Emergency LED Exit 24M - Pro W/wireless
04267	EV-MERCURY-PRO-LK	Ektor Lynk Mercury emergency LED exit - PRO W/wireless

Order code	Item code	Description	Availability
11258	EV-MERCURY-CORE	Mercury Core emergency Exit
11802	EV-MERCURY-CORE-24M-B	Mercury Core Emergency Exit 24m - Black

Order code	Item code	Description
01300	EV-1000mAh-6.4V-LiFePO4	LiFePO4 Battery 6.4V 1000mAh Side-by-side
13972	EV-1500mAh-3.2V-LiFePO4	LiFePO4 Battery 3.2V 1500mAh
01307	EV-1500mAh-3.2V-LiFePO4-Loom	LiFePO4 Battery 3.2V 1500mAh
13845	EV-2000mAh-3.2V-LiFePO4	LiFePO4 Battery 3.2V 2100mAh
01915	EV-CANTILEVER	Cantilever bracket to suit 3135- 3137- 11258 & 3131
11290	EV-MERCURY-BASIC-DP	Mercury Basic decal pack
03922	EV-MERCURY-CASE	Weatherproof Case for Mercury
11220	EV-MERCURY-CD-1	Mercury custom decal to suit 11258 and 3135 - 1pc
11216	EV-MERCURY-CD-2	Mercury Clear Decal to suit 11258 and 3135 - 2pk
01995	EV-MERCURY-DP	Mercury III decal pack
01996	EV-MERCURY-DP-B	Mercury III decal pack - Black
12934	EV-MERCURY-DP-USD	Mercury Basic Decal Pack - Upside down white & green 3 x decals (left- right & straight)
11449	EV-MERCURY-VANDAL-SM	Mercury vandal resistant case - surface mount
03911	EV-MERCURY-WIREGUARD-CEILING	Ceiling mounted only Wire guard
05301	EV-MERCURY-WIREGUARD-WALL	Wall mounted only Wire guard
02004	EV-RODMOUNT-BLK	Rodmount Brackets only for roof and luminaire body - Black (Rod size -25mm)
01990	EV-RODMOUNT-WHT	Rodmount Brackets only for roof and luminaire body - White (Rod size 25mm)
