New product range: Umbra – Special Order Only

Find them here

Product range

Order code Description
EV-UMBRA-ADV-IP65-600-TRI Advanced 600 mm Weatherproof Batten
EV-UMBRA-ADV-IP65-1200-TRI Advanced 1200 mm Weatherproof Batten
FEATURES
  • Tri-colour selection
  • Vandal-proof (IK08)
  • Weatherproof (IP65)
  • Selectable output power
  • Emergency and non-emergency models
BUILT TO LAST
  • Long life electronics
  • LED Lifetime 50,000 hours (L70/B50)
  • 7 Years Design Life – 60,000 hours at max. ambient
SUITABLE INSTALLATION TYPES (OUT OF THE BOX)
  • Standalone (SPU)

This is a non-emergency product This product is also available as emergency model

Downloads

Specifications

General
Supply voltage 240V ~ 50Hz
Ambient temperature 0 – 40°C
Class 1
Wiring Terminal block (1-16 mm □)
Mounting type Surface
IP Rating IP65
IK Rating IK08
CRI 80
SDCM < 6
Lamp Power
600 mm 9 / 17 W
1200 mm 22 / 38 W
Colour temp. Lumens -600 Lumens -1200
4000K 1895 lm 4445 lm
5000K 1970 lm 4680 lm
6500K 1860 lm 4400 lm
Compliance
Standards
  • AS 60598.2.21
  • AS CISPR 15
