In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Maximum Wattage
2 W
Standby Power
0.45 W
Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge.
Working Temp Range
0 to 40 °C
Colour temperature
LED Wattage
1.4 W
Driver
Dimmable
No
Driver Included
Yes
Integrated Driver
Yes
Driver Type
Fixed output
Flex & Plug or Lead Length
1200 mm
Wiring Type
Re-wireable Flex & Plug (2 pin)
Emergency (EM suffix)
Replacement Battery Code
01307
Emergency Classification
C0:D40, C90:D40
Emergency Duration
90 mins
Emergency Lumen Output
200 lm
Emergency Mode
Non-Maintained
Emergency Output Power
1400 mW
Compliance
Product Design Life
6 years
The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.
